| Nombor Bahagian | A030JTN01.1 |
| Jenama | AUO |
| Saiz | 3.0 |
| Permohonan | DSC |
| Resolusi | 960×480(dot) |
| Komposisi | LCM |
| Kecerahan | 550 |
| CR | 300:1 |
| Warna | 16.7M |
| Lampu latar | WLED |
| Antara muka | YUV |
| jenama panel | AUO |
| model panel | A030JTN01.1 |
| jenis panel | LTPS TFT-LCD , LCM |
| saiz panel | 3.0 inch |
| resolusi | 960×480 |
| mod paparan | TN, Normally White, Transmissive |
| kawasan aktif | 60×45 mm |
| garis besar | 69.65×50.9 mm |
| permukaan | Hard coating |
| kecerahan | 550 cd/m² (Typ.) |
| nisbah kontras | 300:1 (Typ.) |
| warna paparan | 16.7M (8-bit), CIE193144% |
| masa tindak balas | 10/25 (Typ.)(Tr/Td) |
| sudut pandangan | 45/45/20/45 (Typ.)(CR≥10)0(L/R/U/D) |
| kekerapan | 60Hz |
| jenis lampu | 4S1PWLEDWithout Driver |
| antara muka isyarat | YUV (16-bit), 47 pins |
| voltan masukan | 3.3/3.3V (Typ.)(VDD/VDDIO) |
| permohonan | DSC |
