| Nombor Bahagian | 24QVF2H |
| Jenama | SII |
| Saiz | 2.4 |
| Permohonan | HHP |
| Resolusi | 240×320 |
| Komposisi | LCM |
| Kecerahan | 300 |
| CR | 800:1 |
| Warna | 262K |
| Lampu latar | WLED |
| Antara muka | TTL |
| jenama panel | SII |
| model panel | 24QVF2H |
| jenis panel | a-Si TFT-LCD , LCM |
| saiz panel | 2.4 inch |
| resolusi | 240(RGB)×320 , QVGA |
| mod paparan | IPS, Normally Black, Transmissive |
| kawasan aktif | 36.72×48.96 mm |
| garis besar | 42.72×60.4 mm |
| permukaan | Clear, Hard coating |
| kecerahan | 300 cd/m² (Typ.) |
| nisbah kontras | 800:1 (Typ.) |
| warna paparan | 262K (6-bit), CIE193172% |
| masa tindak balas | 35 (Typ.)(Tr+Td) |
| sudut pandangan | 80/80/80/80 (Typ.)(CR≥10)(L/R/U/D) |
| jenis lampu | 4S1PWLED |
| antara muka isyarat | Parallel RGB (1 ch, 6-bit) + SPI, 35 pins |
| voltan masukan | (1.65~3.3)/(2.5~3.3)(IOVCC/VCI) |
| permohonan | HHP |
