| Nombor Bahagian | ZV190E0M-N10 |
| Jenama | BOE |
| Saiz | 19.0 |
| Permohonan | Industrial |
| Resolusi | 1280×1024 |
| Komposisi | LCM, a-Si TFT-LCD |
| Kecerahan | |
| CR | 1000:1 |
| Warna | 16.7M |
| Lampu latar | WLED |
| Antara muka | LVDS |
| pengilang | BOE |
| nama model | ZV190E0M-N10 |
| saiz skrin | 19.0 inch |
| jenis skrin | LCM, a-Si TFT-LCD |
| nombor piksel | 1280(RGB)×1024 (SXGA) 86PPI |
| susunan | RGB Vertical Stripe |
| kawasan aktif (mm) | 374.784 × 299.827 (H×V) |
| garis besar (mm) | 396 × 324 × 13.38 (H×V×D) |
| kawasan bezel (mm) | 378.8 × 303 (H×V) |
| rawatan | - |
| kecerahan | 450 cd/m² (Typ.) |
| nisbah kontras | 1000 : 1 (Typ.) (TM) |
| sudut pandangan | 89/89/89/89 (Typ.)(CR≥10) |
| tindak balas | 14 (Typ.)(G to G) ms |
| pandangan yang baik di | Symmetry |
| mod kerja | ADS, Normally Black, Transmissive |
| kedalaman warna | 16.7M 90% NTSC |
| lampu latar | WLED , 50K hours , With LED Driver |
| jisim | 1.80Kgs (Typ.) |
| digunakan untuk | Industrial |
| kadar segar semula | 60Hz |
| skrin sentuh | Without |
| jenis isyarat | LVDS (2 ch, 8-bit) , Connector 30 pins |
| bekalan voltan | 5.0V (Typ.) |
| maks. penilaian | Storage Temp.: -20 ~ 75 °C Operating Temp.: -20 ~ 70 °C |
