| Nombor Bahagian | WF57STIACDNT0 |
| Jenama | Winstar |
| Saiz | 5.7 |
| Permohonan | Industrial |
| Resolusi | 320×240 |
| Komposisi | LCM, a-Si TFT-LCD |
| Kecerahan | |
| CR | 800:1 |
| Warna | Grayscale |
| Lampu latar | WLED |
| Antara muka | 8/16-bit |
| pengilang | Winstar |
| nama model | WF57STIACDNT0 |
| saiz skrin | 5.7 inch |
| jenis skrin | LCM, a-Si TFT-LCD |
| nombor piksel | 320×240 (QVGA) 70PPI |
| susunan | Rectangle |
| kawasan aktif (mm) | 115.2 × 86.4 (H×V) |
| garis besar (mm) | 160 × 109 × 9 (H×V×D) |
| kawasan bezel (mm) | 118.2 × 87.4 (H×V) |
| rawatan | Antiglare |
| kecerahan | 700 cd/m² (Typ.) |
| nisbah kontras | 800 : 1 (Typ.) (TM) |
| sudut pandangan | - |
| tindak balas | - |
| pandangan yang baik di | 12 o'clock |
| mod kerja | TN, Normally White, Transmissive |
| kedalaman warna | Grayscale |
| lampu latar | WLED , No Driver |
| jisim | - |
| digunakan untuk | Industrial |
| kadar segar semula | - |
| skrin sentuh | 4-wire Resistive Touch |
| jenis isyarat | 8/16-bit 6800/8080 parallel, 3/4-wire SPI , FPC 22 pins |
| bekalan voltan | 3.3V (Typ.) |
| maks. penilaian | Storage Temp.: -30 ~ 80 °C Operating Temp.: -20 ~ 70 °C |
