| Nombor Bahagian | WF57STIACDNN0 |
| Jenama | Winstar |
| Saiz | 5.7 |
| Permohonan | Industrial |
| Resolusi | 320×240 |
| Komposisi | a-Si TFT-LCD , LCM |
| Kecerahan | |
| CR | 800:1 |
| Warna | Grayscale |
| Lampu latar | WLED |
| Antara muka | 8/16-bit |
| jenama panel | Winstar |
| saiz panel | 5.7" |
| resolusi | 320×240, QVGA, 70PPI |
| kawasan paparan | 115.2(W)×86.4(H) mm |
| saiz garis besar | 160(W)×109(H) ×7.5(D) mm |
| kecerahan | 1000 cd/m² (Typ.) |
| sudut pandangan | - |
| pandangan terbaik pada | 12 o'clock |
| warna paparan | Grayscale |
| kekerapan | - |
| berat panel | - |
| antara muka isyarat | 8/16-bit 6800/8080 parallel, 3/4-wire SPI , 22 pins FPC |
| voltan masukan | 3.3V (Typ.) |
| persekitaran | Operating Temp.: -20 ~ 70 °C ; Storage Temp.: -30 ~ 80 °C |
| model panel | WF57STIACDNN0 |
| jenis panel | a-Si TFT-LCD , LCM |
| format piksel | Rectangle |
| pembukaan bezel | 122.0(W)×92.0(H) mm |
| permukaan | Glare (Haze 0%) |
| nisbah kontras | 800:1 (Typ.) (TM) |
| mod paparan | TN, Normally White, Transmissive |
| masa tindak balas | - |
| jenis lampu | WLED , Without Driver |
| skrin sentuh | Without |
| permohonan | Industrial |
| AM-640480G2TNQW-T01H-A | AMPIRE | 5.7 | 640×480 |
| G057VGE-T01 | Innolux | 5.7 | 640×480 |
| G057VN01 V0 | AUO | 5.7 | 640×480 |
| KG057QV1CA-G04 | Kyocera | 5.7 | 320×240 |
| KG057QV1DB-G00 | Kyocera | 5.7 | 320×240 |
| LTA057A341F | TOSHIBA | 5.7 | 320×240 |
| LTA057A344F | TOSHIBA | 5.7 | 320×240 |
| NL6448BC18-01 | NLT | 5.7 | 640×480 |
| SP14Q002-A1 | KOE | 5.7 | 320×240 |
| TX14D12VM1CBA | KOE | 5.7 | 320×240 |
