| Nombor Bahagian | WF39BTLASDNG0 |
| Jenama | Winstar |
| Saiz | 3.9 |
| Permohonan | Industrial Stretched |
| Resolusi | 480×128 |
| Komposisi | a-Si TFT-LCD, LCM |
| Kecerahan | |
| CR | 500:1 |
| Warna | 16.7M |
| Lampu latar | WLED |
| Antara muka | Parallel |
| jenama panel | Winstar |
| model panel | WF39BTLASDNG0 |
| saiz panel | 3.9" (1/2 cut of 4.3") |
| jenis panel | a-Si TFT-LCD, LCM |
| resolusi | 480×128(RGB), 128PPI |
| format piksel | RGB Horizontal Stripe |
| kawasan paparan | 95.04(W)×25.34(H) mm |
| pembukaan bezel | 97.04(W)×27.34(H) mm |
| saiz garis besar | 105.5(W)×37(H) ×5.63(D) mm |
| permukaan | Glare (Haze 0%) |
| kecerahan | 400 cd/m² (Typ.) |
| nisbah kontras | 500:1 (Typ.) (TM) |
| sudut pandangan | - |
| mod paparan | TN, Normally White, Transmissive |
| pandangan terbaik pada | 6 o'clock |
| masa tindak balas | - |
| warna paparan | 16.7M |
| jenis lampu | WLED , Without Driver |
| kekerapan | - |
| skrin sentuh | PCAP |
| berat panel | - |
| permohonan | Industrial Stretched Bar LCD |
| antara muka isyarat | Parallel RGB (1 ch, 8-bit) , 40 pins FPC |
| voltan masukan | 3.3V (Typ.) |
| persekitaran | Operating Temp.: -20 ~ 70 °C ; Storage Temp.: -30 ~ 80 °C |
