| Nombor Bahagian | WEO009616AW |
| Jenama | Winstar |
| Saiz | 0.84 |
| Permohonan | Wearable |
| Resolusi | 96×16 |
| Komposisi | PM-OLED , OLED |
| Kecerahan | |
| CR | |
| Warna | Mono(White) |
| Lampu latar | self |
| Antara muka | I²C |
| jenama | Winstar |
| saiz pepenjuru | 0.84 inch |
| format piksel | 96×16 115PPI |
| kawasan aktif | 21.104(H)×3.504(V) mm |
| kawasan bezel | 23.104(H)×5.504(V) mm |
| arah pandang | Symmetry |
| sudut pandangan | - |
| warna sokongan | Mono(White) |
| berat badan | - |
| kadar bingkai | - |
| perincian d-ic | COG Built-in SSD1306BZ |
| jenis antara muka | I²C , 14 pins FPC |
| bekalan kuasa | 3.0V (Typ.) |
| persekitaran | Operating Temperature: -40 ~ 85 °C ; Storage Temperature: -40 ~ 85 °C |
| model | WEO009616AW |
| menaip | PM-OLED , OLED |
| konfigurasi | Rectangle |
| garis besar malap. | 29.1(H)×9.2(V) ×1.46(D) mm |
| rawatan | - |
| masa tindak balas | - |
| mod operasi | - |
| sumber cahaya | self |
| direka untuk | Wearable |
| panel sentuh | Without |
| UG-9616TLBBG01 | WiseChip | 0.84 | 96×16 |
| UG-9616TSWBG01 | WiseChip | 0.84 | 96×16 |
