| Nombor Bahagian | WEO006448AL |
| Jenama | Winstar |
| Saiz | 0.66 |
| Permohonan | Wearable Healthcare |
| Resolusi | 64×48 |
| Komposisi | OLED, PM-OLED |
| Kecerahan | |
| CR | |
| Warna | Mono(Yellow) |
| Lampu latar | self |
| Antara muka | 8-bit |
| pengilang | Winstar |
| nama model | WEO006448AL |
| saiz skrin | 0.66 inch |
| jenis skrin | OLED, PM-OLED |
| nombor piksel | 64×48 121PPI |
| susunan | Rectangle |
| kawasan aktif (mm) | 13.42 × 10.06 (H×V) |
| garis besar (mm) | 18.46 × 18.1 × 1.46 (H×V×D) |
| kawasan bezel (mm) | 15.42 × 12.06 (H×V) |
| rawatan | - |
| sudut pandangan | - |
| tindak balas | - |
| pandangan yang baik di | Symmetry |
| mod kerja | - |
| kedalaman warna | Mono(Yellow) |
| lampu latar | self |
| jisim | - |
| digunakan untuk | Wearable Healthcare |
| kadar segar semula | - |
| skrin sentuh | Without |
| senarai ic pemandu | Built-in COG SSD1306BZ |
| jenis isyarat | 8-bit 6800/8080 parallel, 4-wire SPI, I²C , FPC 28 pins |
| bekalan voltan | 3.3V (Typ.) |
| maks. penilaian | Storage Temp.: -40 ~ 80 °C Operating Temp.: -40 ~ 80 °C |
| DLC0066ANOG-Y | Other | 0.66 | 64×48 |
| UG-6448HLBEG03 | WiseChip | 0.66 | 64×48 |
