| Nombor Bahagian | WEO006432AW |
| Jenama | Winstar |
| Saiz | 0.49 |
| Permohonan | Wearable |
| Resolusi | 64×32 |
| Komposisi | PM-OLED , OLED |
| Kecerahan | |
| CR | |
| Warna | Mono(White) |
| Lampu latar | self |
| Antara muka | I²C |
| jenama panel | Winstar |
| saiz panel | 0.49" |
| resolusi | 64×32, 145PPI |
| kawasan paparan | 11.18(W)×5.58(H) mm |
| saiz garis besar | 14.5(W)×11.6(H) ×1.46(D) mm |
| sudut pandangan | - |
| pandangan terbaik pada | Symmetry |
| warna paparan | Mono(White) |
| kekerapan | - |
| ic pemandu | COG Built-in SSD1306BZ |
| berat panel | - |
| antara muka isyarat | I²C , 14 pins FPC |
| voltan masukan | 3.0/7.5V (Typ.)(VDD/VCC) |
| persekitaran | Operating Temp.: -40 ~ 85 °C ; Storage Temp.: -40 ~ 85 °C |
| model panel | WEO006432AW |
| jenis panel | PM-OLED , OLED |
| format piksel | Rectangle |
| pembukaan bezel | 12.58(W)×6.58(H) mm |
| permukaan | - |
| mod paparan | - |
| masa tindak balas | - |
| jenis lampu | self |
| skrin sentuh | Without |
| permohonan | Wearable |
