| Nombor Bahagian | WEO002004CG |
| Jenama | Winstar |
| Saiz | 2.9 |
| Permohonan | Instruments & Me |
| Resolusi | 5×8 |
| Komposisi | OLED , PM-OLED |
| Kecerahan | |
| CR | 2000:1 |
| Warna | Mono(Green) |
| Lampu latar | self |
| Antara muka | 8-bit |
| pengilang | Winstar |
| nama model | WEO002004CG |
| saiz skrin | 2.9 inch |
| jenis skrin | OLED , PM-OLED |
| nombor char | 20 characters × 4 lines 7PPI |
| format char | 5×8 dots |
| char pitch(mm) | 3.55×5.35 (H×V) |
| saiz aksara (mm) | 2.97×4.77 (H×V) |
| kawasan aktif (mm) | 70.42 × 20.85 (H×V) |
| garis besar (mm) | 84.5 × 27.5 × 2.25 (H×V×D) |
| kawasan bezel (mm) | 72.42 × 22.82 (H×V) |
| rawatan | - |
| kecerahan | - |
| nisbah kontras | 2000 : 1 (Typ.) (TM) |
| sudut pandangan | 88/88/88/88 |
| tindak balas | 0.01 (Typ.) ms |
| pandangan yang baik di | Symmetry |
| mod kerja | - |
| kedalaman warna | Mono(Green) |
| lampu latar | self |
| jisim | - |
| digunakan untuk | Instruments & Meters |
| kadar segar semula | - |
| skrin sentuh | Without |
| senarai ic pemandu | Built-in COG SSD1311M1Z |
| jenis isyarat | 8-bit 6800/8080 parallel, 4-wire SPI, I²C , 32 pins FPC |
| bekalan voltan | 3.3/5.0V (Typ.)(VDD) |
| ACX399CMP-7 | SONY | 2.9 | 640×360 |
| AL2002A | Other | 2.9 | 20×2 |
| LS029B4DN01 | SHARP | 2.9 | 240×456 |
| SC2002A | Other | 2.9 | 20×2 |
| SC2004C | Other | 2.9 | 20×4 |
| SG12864A | Other | 2.9 | 128×64 |
