| Nombor Bahagian | WEH000802AL |
| Jenama | Winstar |
| Saiz | 1.2 |
| Permohonan | Instruments & Meters |
| Resolusi | 5×8 |
| Komposisi | OLED , PM-OLED |
| Kecerahan | |
| CR | |
| Warna | Mono(Yellow) |
| Lampu latar | self |
| Antara muka | |
| pengilang | Winstar |
| saiz skrin | 1.2 inch |
| nombor char | 8 characters × 2 lines 6PPI |
| char pitch(mm) | 3.6×6.3 (H×V) |
| kawasan aktif (mm) | 28.16 × 11.89 (H×V) |
| kawasan bezel (mm) | 38 × 16 (H×V) |
| sudut pandangan | - |
| pandangan yang baik di | Symmetry |
| kedalaman warna | Mono(Yellow) |
| jisim | - |
| kadar segar semula | - |
| nama model | WEH000802AL |
| jenis skrin | OLED , PM-OLED |
| format char | 5×8 dots |
| saiz aksara (mm) | 2.96×5.56 (H×V) |
| garis besar (mm) | 58 × 32 × 10 (H×V×D) |
| rawatan | - |
| mod kerja | - |
| tindak balas | - |
| lampu latar | self |
| digunakan untuk | Instruments & Meters |
| skrin sentuh | Without |
