| Nombor Bahagian | WB014ZNM-N00 |
| Jenama | BOE |
| Saiz | 1.39 |
| Permohonan | Wearable Round Displ |
| Resolusi | 454×454 |
| Komposisi | AM-OLED , OLED |
| Kecerahan | |
| CR | 20000:1 |
| Warna | 16.7M |
| Lampu latar | self |
| Antara muka | MIPI |
| jenama panel | BOE |
| saiz panel | 1.39" |
| resolusi | 454(RGB)×454, 325PPI |
| kawasan paparan | 35.412(W)×35.412(H) mm |
| saiz garis besar | 38.212(W)×39.372(H) mm |
| kecerahan | 350 cd/m² (Typ.) |
| sudut pandangan | 80/80/80/80 (Typ.)(CR≥10) |
| pandangan terbaik pada | Symmetry |
| warna paparan | 16.7M 103% NTSC |
| kekerapan | 60Hz |
| ic pemandu | COG Built-in RM67162FI |
| berat panel | 2.64g |
| antara muka isyarat | MIPI (1 data lane) , 20 pins Connector |
| voltan masukan | 1.8/3.0/4.6/-2.4V (Typ.)(VDDIO/VCI/ELVDD/ELVSS) |
| persekitaran | Operating Temp.: -20 ~ 70 °C ; Storage Temp.: -40 ~ 85 °C |
| model panel | WB014ZNM-N00 |
| jenis panel | AM-OLED , OLED |
| format piksel | RGB Vertical Stripe |
| pembukaan bezel | - |
| permukaan | With Polarizer |
| nisbah kontras | 20000:1 (Typ.) (TM) |
| mod paparan | - |
| masa tindak balas | 3 (Max.)(Tr+Td) |
| jenis lampu | self |
| skrin sentuh | Without |
| permohonan | Wearable Round Display |
