| Nombor Bahagian | VVX07F023B00 |
| Jenama | Panasonic |
| Saiz | 7.0 |
| Permohonan | PAD |
| Resolusi | 1200×1920 |
| Komposisi | LCM |
| Kecerahan | 430 |
| CR | 1000:1 |
| Warna | 16.7M |
| Lampu latar | WLED |
| Antara muka | MIPI |
| jenama panel | Panasonic |
| model panel | VVX07F023B00 |
| jenis panel | a-Si TFT-LCD , LCM |
| saiz panel | 7.0 inch |
| resolusi | 1200(RGB)×1920 , WUXGA |
| mod paparan | IPS, Normally Black, Transmissive |
| kawasan aktif | 94.5×151.2 mm |
| garis besar | 104×161.37×3.9 mm |
| permukaan | Antireflection |
| kecerahan | 430 cd/m² (Typ.) |
| nisbah kontras | 1000:1 (Typ.) |
| warna paparan | 16.7M (8-bit), CIE193160% |
| masa tindak balas | 30 (Max.)(Tr+Td) |
| sudut pandangan | 80/80/80/80 (Min.)(CR≥100)(L/R/U/D) |
| kekerapan | 60Hz |
| jenis lampu | 4S6PWLEDEmbedded (LED Driver) |
| antara muka isyarat | MIPI (4 data lanes), 31 pins |
| voltan masukan | 3.4V (Typ.) |
| permohonan | PAD |
| AT070TN83 V.3 | Innolux | 7.0 | 800×480 |
| B070EAN01.6 | AUO | 7.0 | 800×1280 |
| CLAA069LC01XW | CPT | 7.0 | 800×480 |
| CLAA070NP01 | CPT | 7.0 | 1024×600 |
| LD070WX3-SL01 | LG Display | 7.0 | 800×1280 |
| LQ070T5BG01 | SHARP | 7.0 | 480×234 |
| LQ070Y5DG11 | SHARP | 7.0 | 800×480 |
| LTA070B052F | TOSHIBA | 7.0 | 800×480 |
| VVX07F015M00 | Panasonic | 7.0 | 1200×1920 |
| VVX07F023B00 | Panasonic | 7.0 | 1200×1920 |
| CLAA070WP03XG | CPT | 7.0 | 800×1280 |
| HJ070IA-04K | Innolux | 7.0 | 800×1280 |
| HV121WX4-120 | HYDIS | 12.1 | 1280×800 |
| LP101WH4-SLA3 | LG Display | 10.1 | 1366×768 |
| LP116WH4-SLN2 | LG Display | 11.6 | 1366×768 |
| LTL101AL06-104 | Samsung | 10.1 | 1280×800 |
| N080ICE-GB1 | Innolux | 8.0 | 800×1280 |
| TFTMD089030 | JDI | 8.9 | 2560×1600 |
| VVX10F011B00 | Panasonic | 10.1 | 1920×1200 |
| VVX11F019G00 | Panasonic | 11.6 | 1920×1080 |
