| Nombor Bahagian | VLT270-SBL-FHD-168 |
| Jenama | Vitrolight |
| Saiz | 24.4 |
| Permohonan | Digital Signage Stre |
| Resolusi | 1920×540 |
| Komposisi | a-Si TFT-LCD, LCM |
| Kecerahan | |
| CR | 1000:1 |
| Warna | 16.7M |
| Lampu latar | WLED |
| Antara muka | LVDS |
| jenama panel | Vitrolight |
| model panel | VLT270-SBL-FHD-168 |
| saiz panel | 24.4" (1/2 cut of 27.0") |
| jenis panel | a-Si TFT-LCD, LCM |
| resolusi | 1920(RGB)×540, 81PPI |
| format piksel | RGB Vertical Stripe |
| kawasan paparan | 597.6(W)×168(H) mm |
| pembukaan bezel | - |
| saiz garis besar | 630(W)×200(H) mm |
| permukaan | - |
| kecerahan | 500 cd/m² (Typ.) |
| nisbah kontras | 1000:1 (Typ.) (TM) |
| sudut pandangan | 85/85/80/80 (Typ.)(CR≥10) |
| mod paparan | TN, Normally White, Transmissive |
| pandangan terbaik pada | - |
| masa tindak balas | 3.8 (Typ.)(G to G) |
| warna paparan | 16.7M 72% NTSC |
| jenis lampu | WLED |
| kekerapan | 60Hz |
| skrin sentuh | Without |
| berat panel | - |
| permohonan | Digital Signage Stretched Bar LCD |
| antara muka isyarat | LVDS (2 ch, 8-bit) Connector |
| persekitaran | Operating Temp.: 0 ~ 50 °C ; - |
