| Nombor Bahagian | VLT170-SBL-SXGA-135 |
| Jenama | Vitrolight |
| Saiz | 14.3 |
| Permohonan | Stretched Bar LCD Di |
| Resolusi | 1280×512 |
| Komposisi | a-Si TFT-LCD, LCM |
| Kecerahan | |
| CR | 1000:1 |
| Warna | 16.7M |
| Lampu latar | WLED |
| Antara muka | LVDS |
| jenama panel | Vitrolight |
| model panel | VLT170-SBL-SXGA-135 |
| saiz panel | 14.3" (1/2 cut of 17.0") |
| jenis panel | a-Si TFT-LCD, LCM |
| resolusi | 1280(RGB)×512, 96PPI |
| format piksel | RGB Vertical Stripe |
| kawasan paparan | 337.92(W)×135(H) mm |
| pembukaan bezel | 341.92(W)×140.85(H) mm |
| saiz garis besar | 358.5(W)×162(H) ×10.3(D) mm |
| permukaan | - |
| kecerahan | 400 cd/m² (Typ.) |
| nisbah kontras | 1000:1 (Typ.) (TM) |
| sudut pandangan | 85/85/80/80 (Typ.)(CR≥10) |
| mod paparan | TN, Normally White, Transmissive |
| pandangan terbaik pada | - |
| masa tindak balas | 3.8 (Typ.)(G to G) |
| warna paparan | 16.7M 72% NTSC |
| jenis lampu | WLED |
| kekerapan | 60Hz |
| skrin sentuh | Without |
| berat panel | - |
| permohonan | Stretched Bar LCD Digital Signage |
| antara muka isyarat | LVDS (2 ch, 8-bit) |
| persekitaran | Operating Temp.: 0 ~ 50 °C ; - |
