Innolux V650HP1-PS6 Rev.C1 lembaran data, spesifikasi, stok, aplikasi www.looklcd-my.com
LookLCD LookLCD


V650HP1-PS6 Rev.C1

V650HP1-PS6 Rev.C1
V650HP1-PS6 Rev.C1
V650HP1-PS6 Rev.C1 thumb V650HP1-PS6 Rev.C1 thumb
Jenama
Innolux
Saiz
65
Permohonan
LCTV
Resolusi
1920×1080
Komposisi
CELL
Kecerahan
0
CR
5000:1
Warna
1.07B
Lampu latar
No B/L
Antara muka
LVDS
In Stock
17820
Spesifikasi

Nombor Bahagian V650HP1-PS6 Rev.C1
JenamaInnolux
Saiz65
PermohonanLCTV
Resolusi1920×1080
KomposisiCELL
Kecerahan0
CR5000:1
Warna1.07B
Lampu latarNo B/L
Antara mukaLVDS
jenama panelCHIMEI INNOLUX
model panelV650HP1-PS6 Rev.C1
jenis panel a-Si TFT-LCD , CELL
saiz panel65 inch
resolusi1920(RGB)×1080 , FHD
mod paparanSuper MVA, Normally Black, Transmissive
kawasan aktif1428.48×803.52 mm
garis besar1455.76×856.12 mm
permukaanAntiglare (Haze 1%)
kedalaman kaca0.70+0.70 mm
ketransmisian6.5% (Typ.)(with Polarizer)
nisbah kontras5000:1 (Typ.)
warna paparan1.07B (8-bit + Hi-FRC)
masa tindak balas6.5 (Typ.)(G to G)
sudut pandangan88/88/88/88 (Typ.)(CR≥20)(L/R/U/D)
kekerapan120Hz
antara muka isyaratLVDS (4 ch, 10-bit), 102 pins
voltan masukan12.0V (Typ.)
permohonanLCTV
