| Nombor Bahagian | V500HJ1-PE8 Rev.C7 |
| Jenama | Chimei Innolux |
| Saiz | 50 |
| Permohonan | Transparent Display |
| Resolusi | 1920×1080 |
| Komposisi | a-Si TFT-LCD, CELL |
| Kecerahan | |
| CR | 5000:1 |
| Warna | 16.7M |
| Lampu latar | No |
| Antara muka | LVDS |
| jenama | Chimei Innolux |
| model | V500HJ1-PE8 Rev.C7 |
| saiz pepenjuru | 50 inch |
| menaip | a-Si TFT-LCD, CELL |
| format piksel | 1920(RGB)×1080 [FHD] 44PPI |
| konfigurasi | RGB Vertical Stripe |
| kawasan aktif | 1095.84(H)×616.41(V) mm |
| garis besar malap. | 1116.38(H)×631.61(V) ×1.31(D) mm |
| kawasan bezel | - |
| rawatan | Antiglare (Haze 1%), Hard coating (3H) |
| kecerahan | 0 cd/m² |
| nisbah kontras | 5000:1 (Typ.) (TM) |
| arah pandang | Symmetry |
| masa tindak balas | 8.5 (Typ.)(G to G) |
| sudut pandangan | 88/88/88/88 (Typ.)(CR≥20) |
| mod operasi | Super MVA, Normally Black, Transmissive |
| ketebalan plat | - |
| penghantaran | 5.6% (Typ.)(with Polarizer) |
| warna sokongan | 16.7M 70% NTSC |
| sumber cahaya | No B/L |
| berat badan | 1.99±0.199Kgs |
| direka untuk | Transparent Display |
| kadar bingkai | 60Hz |
| panel sentuh | Without |
| perincian d-ic | COF Built-in 6 source + 4 gate chips |
| jenis antara muka | LVDS (2 ch, 8-bit) Connector |
| bekalan kuasa | 12.0V (Typ.) |
| persekitaran | Operating Temperature: 0 ~ 50 °C ; Storage Temperature: -20 ~ 60 °C |
