V460H1-LS1 Rev.C6

V460H1-LS1 Rev.C6
V460H1-LS1 Rev.C6
V460H1-LS1 Rev.C6
V460H1-LS1 Rev.C6 thumb V460H1-LS1 Rev.C6 thumb V460H1-LS1 Rev.C6 thumb
Jenama
Innolux
Saiz
46
Permohonan
LCTV
Resolusi
1920×1080
Komposisi
LCM
Kecerahan
350
CR
6000:1
Warna
1.07B
Lampu latar
WLED
Antara muka
LVDS
In Stock
19025
Spesifikasi

Nombor Bahagian V460H1-LS1 Rev.C6
JenamaInnolux
Saiz46
PermohonanLCTV
Resolusi1920×1080
KomposisiLCM
Kecerahan350
CR6000:1
Warna1.07B
Lampu latarWLED
Antara mukaLVDS
jenama panelCHIMEI INNOLUX
model panelV460H1-LS1 Rev.C6
jenis panel a-Si TFT-LCD , LCM
saiz panel46 inch
resolusi1920(RGB)×1080 , FHD
mod paparanSuper MVA, Normally Black, Transmissive
kawasan aktif1018.08×572.67 mm
garis besar1076.5×634.7 mm
permukaanAntiglare (Haze 11%), Hard coating (3H)
kecerahan350 cd/m² (Typ.)
nisbah kontras6000:1 (Typ.)
warna paparan1.07B (8-bit + Hi-FRC), CIE193172%
masa tindak balas6 (Typ.)(G to G)
sudut pandangan88/88/88/88 (Typ.)(CR≥20)(L/R/U/D)
kekerapan120Hz
jenis lampu4 stringsWLEDEmbedded (LED Driver)
antara muka isyaratLVDS (4 ch, 10-bit), 102 pins
voltan masukan12.0V (Typ.)
permohonanLCTV
Model Keluarga
LTA460HQ16 Samsung 46 1920×1080
T460HW04 V8 AUO 46 1920×1080
V460H1-L09 Innolux 46 1920×1080
V460H1-L12 Innolux 46 1920×1080
V460H1-LE3 Innolux 46 1920×1080
V460H1-LH9 Innolux 46 1920×1080
V460H1-LS1 Innolux 46 1920×1080
V460H1-LS1 Rev.C6 Innolux 46 1920×1080
V460H1-LS2 Innolux 46 1920×1080
V460H1-LS2 Rev.C7 Innolux 46 1920×1080
