| Nombor Bahagian | V450HJ1-Q01 Rev.C1 |
| Jenama | Innolux |
| Saiz | 44.5 |
| Permohonan | TV Sets |
| Resolusi | 1920×1080 |
| Komposisi | a-Si TFT-LCD, CELL |
| Kecerahan | |
| CR | 4800:1 |
| Warna | 16.7M |
| Lampu latar | No |
| Antara muka | LVDS |
| jenama panel | Innolux |
| model panel | V450HJ1-Q01 Rev.C1 |
| saiz panel | 44.5" |
| jenis panel | a-Si TFT-LCD, CELL |
| resolusi | 1920(RGB)×1080, FHD, 49PPI |
| format piksel | RGB Vertical Stripe |
| kawasan paparan | 989.568(W)×546.264(H) mm |
| pembukaan bezel | - |
| saiz garis besar | 999.568(W)×556.364(H) ×1.3(D) mm |
| permukaan | Antiglare (Haze 1%) |
| kecerahan | 0 cd/m² |
| nisbah kontras | 4800:1 (Typ.) (TM) |
| sudut pandangan | 89/89/89/89 (Typ.)(CR≥10) |
| mod paparan | Super MVA, Normally Black, Transmissive |
| pandangan terbaik pada | Symmetry |
| masa tindak balas | 9.5 (Typ.)(G to G) |
| kedalaman kaca | - |
| ketransmisian | 5.35% (Typ.)(with Polarizer) |
| warna paparan | 16.7M 70% NTSC |
| jenis lampu | No B/L |
| kekerapan | 60Hz |
| skrin sentuh | Without |
| ic pemandu | COFBuilt-in 8 source + 4 gate chips |
| berat panel | 1.64±0.08Kgs |
| permohonan | TV Sets |
| antara muka isyarat | LVDS (2 ch, 8-bit) , 51 pins Connector |
| voltan masukan | 12.0V (Typ.) |
| persekitaran | Operating Temp.: 0 ~ 50 °C ; Storage Temp.: -25 ~ 60 °C |
