Innolux V400H1-L01 lembaran data, spesifikasi, stok, aplikasi www.looklcd-my.com
LookLCD LookLCD


V400H1-L01

V400H1-L01
V400H1-L01
V400H1-L01 thumb V400H1-L01 thumb
Jenama
Innolux
Saiz
40
Permohonan
LCTV
Resolusi
1920×1080
Komposisi
LCM
Kecerahan
530
CR
1800:1
Warna
16.7M
Lampu latar
CCFL
Antara muka
LVDS
In Stock
18447
Spesifikasi

Nombor Bahagian V400H1-L01
JenamaInnolux
Saiz40
PermohonanLCTV
Resolusi1920×1080
KomposisiLCM
Kecerahan530
CR1800:1
Warna16.7M
Lampu latarCCFL
Antara mukaLVDS
jenama panelCHIMEI INNOLUX
model panelV400H1-L01
jenis panel a-Si TFT-LCD , LCM
saiz panel40 inch
resolusi1920(RGB)×1080 , FHD
mod paparanSuper MVA, Normally Black, Transmissive
kawasan aktif885.6×498.15 mm
garis besar952×551 mm
permukaanAntiglare (Haze 25%), Hard coating (3H)
kecerahan530 cd/m² (Typ.)
nisbah kontras1800:1 (Typ.)
warna paparan16.7M (8-bit), CIE193172%
masa tindak balas6.5 (Typ.)(G to G)
sudut pandangan88/88/88/88 (Typ.)(CR≥20)(L/R/U/D)
kekerapan60Hz
jenis lampu20 pcsCCFLEmbedded (Balance board)
antara muka isyaratLVDS (2 ch, 8-bit), 51 pins
voltan masukan12.0V (Typ.)
permohonanLCTV
