| Nombor Bahagian | UG-2828GDEDF15 |
| Jenama | Univision |
| Saiz | 1.5 |
| Permohonan | Mobile Phone Handhel |
| Resolusi | 128×128 |
| Komposisi | PM-OLED, OLED |
| Kecerahan | |
| CR | 2000:1 |
| Warna | 262K |
| Lampu latar | self |
| Antara muka | 8-bit |
| jenama | Univision |
| model | UG-2828GDEDF15 |
| saiz pepenjuru | 1.5 inch |
| menaip | PM-OLED, OLED |
| format piksel | 128(RGB)×128 121PPI |
| konfigurasi | RGB Vertical Stripe |
| kawasan aktif | 26.855(H)×26.864(V) mm |
| garis besar malap. | 33.8(H)×34(V) ×1.7(D) mm |
| kawasan bezel | 28.855(H)×28.864(V) mm |
| rawatan | - |
| kecerahan | 90 cd/m² (Typ.) |
| nisbah kontras | 2000:1 (Typ.) (TM) |
| arah pandang | Symmetry |
| masa tindak balas | - |
| sudut pandangan | 80/80/80/80 (Min.) |
| mod operasi | - |
| warna sokongan | 262K |
| sumber cahaya | self , 20K hours |
| berat badan | 3.80g (Typ.) |
| direka untuk | Mobile Phone Handheld & PDA |
| kadar bingkai | - |
| panel sentuh | Without |
| perincian d-ic | COF Built-in SSD1351 |
| jenis antara muka | 8-bit 6800/8080 parallel, 3/4-wire SPI , 30 pins FPC |
| bekalan kuasa | 2.8/2.5/1.8/13V (Typ.)(VCI/VDD/VDDIO/VCC) |
| persekitaran | Operating Temperature: -30 ~ 70 °C ; Storage Temperature: -40 ~ 80 °C |
