| Nombor Bahagian | TX39D80VC1GAA |
| Jenama | KOE |
| Saiz | 15.4 |
| Permohonan | NBPC |
| Resolusi | 1280×800 |
| Komposisi | LCM |
| Kecerahan | 480 |
| CR | 600:1 |
| Warna | 262K |
| Lampu latar | CCFL |
| Antara muka | LVDS |
| jenama panel | HITACHI |
| model panel | TX39D80VC1GAA |
| jenis panel | a-Si TFT-LCD , LCM |
| saiz panel | 15.4 inch |
| resolusi | 1280(RGB)×800 , WXGA |
| mod paparan | TN, Normally White, Transmissive |
| kawasan aktif | 331.2×207 mm |
| garis besar | 344×225 mm |
| permukaan | Glare (Haze 0%) |
| kecerahan | 480 cd/m² (Typ.) |
| nisbah kontras | 600:1 (Min.) |
| warna paparan | 262K (6-bit) |
| masa tindak balas | 50 (Typ.)(Tr+Td) |
| sudut pandangan | |
| kekerapan | 60Hz |
| jenis lampu | 2 pcsCCFLWithout Driver |
| antara muka isyarat | LVDS (1 ch, 6-bit) |
| voltan masukan | 3.3V (Typ.) |
| rohs: | |
| permohonan | NBPC |
