| Nombor Bahagian | TX31D16VM2BAA |
| Jenama | KOE |
| Saiz | 12.2 |
| Permohonan | CNS |
| Resolusi | 1024×310 |
| Komposisi | LCM |
| Kecerahan | |
| CR | |
| Warna | 262K |
| Lampu latar | CCFL |
| Antara muka | LVDS |
| jenama panel | HITACHI |
| model panel | TX31D16VM2BAA |
| jenis panel | a-Si TFT-LCD , LCM |
| saiz panel | 12.2 inch |
| resolusi | 1024(RGB)×310 |
| mod paparan | TN, Normally White, Transmissive |
| garis besar | 313×110 mm |
| permukaan | |
| kecerahan | |
| nisbah kontras | |
| warna paparan | 262K (6-bit) |
| masa tindak balas | |
| sudut pandangan | |
| jenis lampu | 2 pcsCCFLWithout Driver |
| antara muka isyarat | LVDS (1 ch, 6-bit), 20 pins |
| permohonan | CNS |
