| Nombor Bahagian | TX18D210VM0BAA |
| Jenama | KOE |
| Saiz | 7.0 |
| Permohonan | Industrial Outdoor H |
| Resolusi | 800×480 |
| Komposisi | LCM , LTPS TFT-LCD |
| Kecerahan | |
| CR | 1200:1 |
| Warna | 262K |
| Lampu latar | WLED |
| Antara muka | Parallel |
| pengilang | KOE |
| saiz skrin | 7.0 inch |
| nombor piksel | 800(RGB)×480 (WVGA) 133PPI |
| kawasan aktif (mm) | 152.4 × 91.44 (H×V) |
| kawasan bezel (mm) | 156.2 × 94.5 (H×V) |
| kecerahan | 800 cd/m² (Typ.) |
| sudut pandangan | 85/85/85/85 (Typ.)(CR≥10) |
| pandangan yang baik di | Symmetry |
| kedalaman warna | 262K 72% NTSC |
| jisim | 214g (Typ.) |
| kadar segar semula | 60Hz |
| jenis isyarat | Parallel RGB (1 ch, 6-bit) , 40 pins Connector |
| bekalan voltan | 3.3V (Typ.) |
| maks. penilaian | Storage Temp.: -40 ~ 90 °C Operating Temp.: -40 ~ 85 °C ; Vibration Level: 5.0G (49.0 m/s²) |
| nama model | TX18D210VM0BAA |
| jenis skrin | LCM , LTPS TFT-LCD |
| susunan | RGB Vertical Stripe |
| garis besar (mm) | 167.7 × 109.5 × 20.3 (H×V×D) |
| rawatan | - |
| nisbah kontras | 1200 : 1 (Typ.) (TM) |
| tindak balas | 30 (Typ.)(Tr+Td) ms |
| mod kerja | IPS, Normally Black, Transmissive |
| lampu latar | WLED , 50K hours , With LED Driver |
| digunakan untuk | Industrial Outdoor High Brightness Automotive Display |
| skrin sentuh | Without |
