| Nombor Bahagian | TV105WUM-AS0 |
| Jenama | BOE |
| Saiz | 10.5 |
| Permohonan | Pad & Tablet |
| Resolusi | 1200×1920 |
| Komposisi | Assembly , a-Si TF |
| Kecerahan | |
| CR | 900:1 |
| Warna | 16.7M |
| Lampu latar | 4 |
| Antara muka | MIPI |
| pengilang | BOE |
| saiz skrin | 10.5 inch |
| nombor piksel | 1200(RGB)×1920 (WUXGA) 215PPI |
| kawasan aktif (mm) | 141.3 × 226.08 (H×V) |
| kawasan bezel (mm) | - |
| kecerahan | 480 cd/m² (Typ.) |
| sudut pandangan | 85/85/85/85 (Typ.)(CR≥10) |
| pandangan yang baik di | Symmetry |
| kedalaman warna | 16.7M 92% DCI-P3 |
| jisim | 216g (Typ.) |
| kadar segar semula | 60Hz |
| jenis isyarat | MIPI (4 data lanes) , 34 pins Connector |
| bekalan voltan | 1.8/5.8/-5.8V (Typ.)(VDD/VSP/VSN) |
| maks. penilaian | Storage Temp.: -55 ~ 125 °C Operating Temp.: -20 ~ 85 °C |
| nama model | TV105WUM-AS0 |
| jenis skrin | Assembly , a-Si TFT-LCD |
| susunan | RGB Vertical Stripe |
| garis besar (mm) | 156.18 × 255.06 × 4.44 (H×V×D) |
| rawatan | Hard coating |
| nisbah kontras | 900 : 1 (Typ.) (TM) |
| tindak balas | 25 (Typ.)(Tr+Td) ms |
| mod kerja | - |
| lampu latar | 4 strings WLED , No Driver |
| digunakan untuk | Pad & Tablet |
| skrin sentuh | PCAP |
