| Nombor Bahagian | TV080WXM-NS1 |
| Jenama | BOE |
| Saiz | 8.0 |
| Permohonan | Pad & Tablet |
| Resolusi | 800×1280 |
| Komposisi | a-Si TFT-LCD , LCM |
| Kecerahan | |
| CR | 1100:1 |
| Warna | 16.7M |
| Lampu latar | WLED |
| Antara muka | MIPI |
| jenama | BOE |
| saiz pepenjuru | 8.0 inch |
| format piksel | 800(RGB)×1280 [WXGA] 188PPI |
| kawasan aktif | 107.64(H)×172.224(V) mm |
| kecerahan | 530 cd/m² (Typ.) |
| arah pandang | Symmetry |
| sudut pandangan | 85/85/85/85 (Typ.)(CR≥10) |
| warna sokongan | 16.7M 87% NTSC |
| berat badan | - |
| kadar bingkai | 60Hz |
| jenis antara muka | MIPI (4 data lanes) , 34 pins Connector |
| bekalan kuasa | 1.8/5.4/-5.4V (Typ.)(VDD1/PVDD/NVDD) |
| persekitaran | Operating Temperature: -20 ~ 65 °C ; Storage Temperature: -30 ~ 80 °C |
| model | TV080WXM-NS1 |
| menaip | a-Si TFT-LCD , LCM |
| konfigurasi | RGB Vertical Stripe |
| garis besar malap. | 114.65(H)×183.853(V) ×3.56(D) mm |
| nisbah kontras | 1100:1 (Typ.) (TM) |
| masa tindak balas | 30 (Typ.)(Tr+Td) |
| mod operasi | ADS, Normally Black, Transmissive |
| sumber cahaya | WLED [3 strings] , W/O Driver |
| direka untuk | Pad & Tablet |
| panel sentuh | Without |
