| Nombor Bahagian | TV080WUM-TL1 |
| Jenama | BOE |
| Saiz | 8.0 |
| Permohonan | Pad & Tablet |
| Resolusi | 1200×1920 |
| Komposisi | a-Si TFT-LCD, Assemb |
| Kecerahan | |
| CR | 900:1 |
| Warna | 16.7M |
| Lampu latar | WLED |
| Antara muka | |
| jenama | BOE |
| model | TV080WUM-TL1 |
| saiz pepenjuru | 8.0 inch |
| menaip | a-Si TFT-LCD, Assembly |
| format piksel | 1200(RGB)×1920 [WUXGA] 283PPI |
| konfigurasi | RGB Vertical Stripe |
| kawasan aktif | 107.64(H)×172.224(V) mm |
| garis besar malap. | 117.7(H)×193.84(V) ×5.5(D) mm |
| kawasan bezel | - |
| rawatan | Hard coating |
| kecerahan | 350 cd/m² (Typ.) |
| nisbah kontras | 900:1 (Typ.) (TM) |
| arah pandang | Symmetry |
| masa tindak balas | 30 (Typ.)(Tr+Td) |
| sudut pandangan | 80/80/80/80 (Typ.)(CR≥10) |
| mod operasi | HADS, Normally Black, Transmissive |
| warna sokongan | 16.7M 58% NTSC |
| sumber cahaya | WLED [6S4P] , W/O Driver |
| berat badan | 155g (Max.) |
| direka untuk | Pad & Tablet |
| kadar bingkai | 60Hz |
| panel sentuh | On-Cell Touch |
| Operating Temperature: -20 ~ 60 °C ; Storage Temperature: -30 ~ 70 °C |
