| Nombor Bahagian | TV070WSM-TL1 |
| Jenama | BOE |
| Saiz | 7.0 |
| Permohonan | Pad & Tablet |
| Resolusi | 600×1024 |
| Komposisi | Assembly , a-Si TF |
| Kecerahan | |
| CR | 800:1 |
| Warna | 16.7M |
| Lampu latar | 6S3P |
| Antara muka | MIPI |
| pengilang | BOE |
| nama model | TV070WSM-TL1 |
| saiz skrin | 7.0 inch |
| jenis skrin | Assembly , a-Si TFT-LCD |
| nombor piksel | 600(RGB)×1024 (WSVGA) 170PPI |
| susunan | RGB Vertical Stripe |
| kawasan aktif (mm) | 89.28 × 152.37 (H×V) |
| garis besar (mm) | 97 × 188.26 (H×V×D) |
| kawasan bezel (mm) | - |
| rawatan | Hard coating |
| kecerahan | 300 cd/m² (Typ.) |
| nisbah kontras | 800 : 1 (Typ.) (TM) |
| sudut pandangan | 85/85/85/85 (Typ.)(CR≥10) |
| tindak balas | 30 (Typ.)(Tr+Td) ms |
| pandangan yang baik di | Symmetry |
| mod kerja | - |
| kedalaman warna | 16.7M 50% NTSC |
| lampu latar | 6S3P WLED , No Driver |
| jisim | 125g (Max.) |
| digunakan untuk | Pad & Tablet |
| kadar segar semula | 60Hz |
| skrin sentuh | On-Cell Touch |
| jenis isyarat | MIPI (4 data lanes) , 39 pins Connector |
| bekalan voltan | 3.3V (Typ.) |
| maks. penilaian | Storage Temp.: -20 ~ 70 °C Operating Temp.: -20 ~ 60 °C |
