| Nombor Bahagian | TPM0501010P |
| Jenama | JDI |
| Saiz | 5.0 |
| Permohonan | Mobile Phone |
| Resolusi | 1080×1920 |
| Komposisi | a-Si TFT-LCD, LCM |
| Kecerahan | |
| CR | 1000:1 |
| Warna | 16.7M |
| Lampu latar | WLED |
| Antara muka | MIPI |
| jenama | JDI |
| model | TPM0501010P |
| saiz pepenjuru | 5.0 inch |
| menaip | a-Si TFT-LCD, LCM |
| format piksel | 1080(RGB)×1920 [FHD] 445PPI |
| konfigurasi | RGB Vertical Stripe |
| kawasan aktif | 61.641(H)×109.584(V) mm |
| garis besar malap. | 64.04(H)×116.52(V) ×1.48(D) mm |
| kecerahan | 450 cd/m² (Typ.) |
| nisbah kontras | 1000:1 (Typ.) (TM) |
| arah pandang | Symmetry |
| masa tindak balas | 25 (Typ.)(Tr+Td) |
| sudut pandangan | 80/80/80/80 (Typ.)(CR≥10) |
| mod operasi | IPS, Normally Black, Transmissive |
| warna sokongan | 16.7M 85% NTSC |
| sumber cahaya | WLED [7S2P] , W/O Driver |
| berat badan | TBD |
| direka untuk | Mobile Phone |
| kadar bingkai | 60Hz |
| panel sentuh | In-Cell Touch |
| jenis antara muka | MIPI (4 data lanes) , 40 pins Connector |
| bekalan kuasa | 1.8/5.5/-5.5V (Typ.)(IOVCC/AVDD/AVEE) |
| persekitaran | Operating Temperature: -20 ~ 60 °C ; Storage Temperature: -30 ~ 70 °C |
| AT050TN43 V.1 | Innolux | 5.0 | 800×480 |
| ED050SC3 | E Ink | 5.0 | 800×600 |
| EE050NA-04A | Innolux | 5.0 | 640×480 |
| G050VTN01.1 | AUO | 5.0 | 800×480 |
| G050VVN01.0 | AUO | 5.0 | 480×800 |
| LMS501KF03 | Samsung | 5.0 | 480×800 |
| M050SWN1 R2 | IVO | 5.0 | 480×234 |
| PA050DT2 | E Ink | 5.0 | 320×234 |
| TM050LDZ00 | Tianma | 5.0 | 240×400 |
| TM050RDH03 | Tianma | 5.0 | 800×480 |
