| Nombor Bahagian | TM116VDSP03 |
| Jenama | TIANMA |
| Saiz | 11.6 |
| Permohonan | Industrial Outdoor H |
| Resolusi | 1920×1080 |
| Komposisi | LCM , a-Si TFT-LCD |
| Kecerahan | |
| CR | 900:1 |
| Warna | 16.7M |
| Lampu latar | 9S6P |
| Antara muka | LVDS |
| pengilang | TIANMA |
| nama model | TM116VDSP03 |
| saiz skrin | 11.6 inch |
| jenis skrin | LCM , a-Si TFT-LCD |
| nombor piksel | 1920(RGB)×1080 (FHD) 190PPI |
| susunan | RGB Vertical Stripe |
| kawasan aktif (mm) | 256.32 × 144.18 (H×V) |
| garis besar (mm) | 273.5 × 166.5 × 11.5 (H×V×D) |
| kawasan bezel (mm) | 259.31 × 148.73 (H×V) |
| rawatan | Hard coating |
| kecerahan | 1000 cd/m² (Typ.) |
| nisbah kontras | 900 : 1 (Typ.) (TM) |
| sudut pandangan | 88/88/88/88 (Typ.)(CR≥10) |
| tindak balas | 25 (Typ.)(Tr+Td) ms |
| pandangan yang baik di | Symmetry |
| mod kerja | SFT, Normally Black, Transmissive |
| kedalaman warna | 16.7M 70% NTSC |
| lampu latar | 9S6P WLED , 50K hours , No Driver |
| jisim | TBD |
| digunakan untuk | Industrial Outdoor High Brightness |
| kadar segar semula | 60Hz |
| skrin sentuh | Without |
| jenis isyarat | LVDS (2 ch, 8-bit) , 30 pins Connector |
| bekalan voltan | 3.3/10.7/20/-7V (Typ.)(VCC/AVDD/VGH/VGL) |
| maks. penilaian | Storage Temp.: -30 ~ 85 °C Operating Temp.: -20 ~ 70 °C |
