| Nombor Bahagian | TM101DDHG04 |
| Jenama | TIANMA |
| Saiz | 10.1 |
| Permohonan | Industrial |
| Resolusi | 1024×600 |
| Komposisi | a-Si TFT-LCD , LCM |
| Kecerahan | |
| CR | 800:1 |
| Warna | 262K/16.7M |
| Lampu latar | 10S3P |
| Antara muka | |
| jenama panel | TIANMA |
| saiz panel | 10.1" |
| resolusi | 1024(RGB)×600, WSVGA, 117PPI |
| kawasan paparan | 222.72(W)×125.28(H) mm |
| saiz garis besar | 233.1(W)×137.1(H) ×3.3(D) mm |
| kecerahan | 300 cd/m² (Typ.) |
| sudut pandangan | 80/80/75/80 (Typ.)(CR≥10) |
| pandangan terbaik pada | 12 o'clock |
| warna paparan | 262K/16.7M 47% NTSC |
| kekerapan | 60Hz |
| berat badan | 210/220g (Typ./Max.) |
| model panel | TM101DDHG04 |
| jenis panel | a-Si TFT-LCD , LCM |
| format piksel | RGB Vertical Stripe |
| pembukaan bezel | 225.72(W)×128.28(H) mm |
| permukaan | Antiglare, Hard coating (3H) |
| nisbah kontras | 800:1 (Typ.) (TM) |
| mod paparan | TN, Normally White, Transmissive |
| masa tindak balas | 7/9 (Typ.)(Tr/Td) |
| jenis lampu | 10S3P WLED , 15K hours , Without Driver |
| skrin sentuh | Without |
| permohonan | Industrial |
