| Nombor Bahagian | TM089CFSP01 |
| Jenama | TIANMA |
| Saiz | 8.9 |
| Permohonan | 3D Printer |
| Resolusi | 3840×2400 |
| Komposisi | a-Si TFT-LCD , CELL |
| Kecerahan | |
| CR | 800:1 |
| Warna | Monochrome |
| Lampu latar | No |
| Antara muka | |
| jenama panel | TIANMA |
| saiz panel | 8.9" |
| resolusi | 3840×2400, 508PPI |
| kawasan paparan | 192(W)×120(H) mm |
| saiz garis besar | 202(W)×133(H) ×1.24(D) mm |
| kecerahan | 0 cd/m² |
| sudut pandangan | 85/85/85/85 (Typ.)(CR≥10) |
| pandangan terbaik pada | Symmetry |
| kedalaman kaca | - |
| warna paparan | Monochrome |
| kekerapan | 60Hz |
| berat badan | TBD |
| model panel | TM089CFSP01 |
| jenis panel | a-Si TFT-LCD , CELL |
| format piksel | Rectangle |
| pembukaan bezel | - |
| permukaan | Clear |
| nisbah kontras | 800:1 (Typ.) (TM) |
| mod paparan | SFT, Normally Black, Transmissive |
| masa tindak balas | 25 (Typ.)(Tr+Td) |
| ketransmisian | 5.4% (Typ.)(with Polarizer) |
| jenis lampu | No B/L |
| skrin sentuh | Without |
| permohonan | 3D Printer |
| A089SW01 V0 | AUO | 8.9 | 1024×600 |
| HSD089IFW1-B00 | HannStar | 8.9 | 1024×600 |
| HSD089IFW3-A00 | HannStar | 8.9 | 1024×600 |
| HT089WX1-100 | HYDIS | 8.9 | 1280×768 |
| HV089WX1-100 | HYDIS | 8.9 | 1280×768 |
| KCG089HV1AA-G00 | Kyocera | 8.9 | 640×240 |
| LP089WS1-TLA1 | LG Display | 8.9 | 1024×600 |
| LP089WS2-TLB1 | LG Display | 8.9 | 1024×600 |
| LSUGC202XA | ALPS | 8.9 | 640×240 |
| NL12876BC15-01 | NLT | 8.9 | 1280×768 |
