| Nombor Bahagian | TM084SDHG04 |
| Jenama | TIANMA |
| Saiz | 8.4 |
| Permohonan | Industrial |
| Resolusi | 800×600 |
| Komposisi | a-Si TFT-LCD, LCM |
| Kecerahan | |
| CR | 500:1 |
| Warna | 262K |
| Lampu latar | 8S3P |
| Antara muka | LVDS |
| jenama panel | TIANMA |
| model panel | TM084SDHG04 |
| saiz panel | 8.4" |
| jenis panel | a-Si TFT-LCD, LCM |
| resolusi | 800(RGB)×600, SVGA, 119PPI |
| format piksel | RGB Vertical Stripe |
| kawasan paparan | 170.4(W)×127.8(H) mm |
| pembukaan bezel | 173.0(W)×130.6(H) mm |
| saiz garis besar | 203(W)×143.5(H) ×7.05(D) mm |
| permukaan | Antiglare |
| kecerahan | 350 cd/m² (Typ.) |
| nisbah kontras | 500:1 (Typ.) (TM) |
| sudut pandangan | 70/70/60/70 (Typ.)(CR≥10) |
| mod paparan | TN, Normally White, Transmissive |
| pandangan terbaik pada | 12 o'clock |
| masa tindak balas | 20 (Typ.)(Tr+Td) |
| warna paparan | 262K 40% NTSC |
| jenis lampu | 8S3P WLED , 30K hours , With LED Driver |
| kekerapan | 60Hz |
| skrin sentuh | Without |
| berat panel | 240g (Typ.) |
| permohonan | Industrial |
| antara muka isyarat | LVDS (1 ch, 6-bit) , 20 pins Connector |
| voltan masukan | 3.3V (Typ.) |
| persekitaran | Operating Temp.: -20 ~ 70 °C ; Storage Temp.: -30 ~ 80 °C |
| AA084XB01 | Mitsubishi | 8.4 | 1024×768 |
| B084SN01 V2 | AUO | 8.4 | 800×600 |
| LQ9D001 | SHARP | 8.4 | 640×480 |
| LQ9D024 | SHARP | 8.4 | 640×480 |
| NL6448BC26-27 | NLT | 8.4 | 640×480 |
| TM084SBHG04 | Tianma | 8.4 | 800×600 |
| TM084SDHG01 | Tianma | 8.4 | 800×600 |
| TM084SDHG02 | Tianma | 8.4 | 800×600 |
| TM084SDHG03 | Tianma | 8.4 | 800×600 |
| TM084SDHG50 | Tianma | 8.4 | 800×600 |
