| Nombor Bahagian | TM080VDSP03 |
| Jenama | TIANMA |
| Saiz | 8.0 |
| Permohonan | Pad & Tablet |
| Resolusi | 1200×1920 |
| Komposisi | a-Si TFT-LCD , LCM |
| Kecerahan | |
| CR | 800:1 |
| Warna | 16.7M |
| Lampu latar | 7S3P |
| Antara muka | |
| jenama panel | TIANMA |
| saiz panel | 8.0" |
| resolusi | 1200(RGB)×1920, WUXGA, 283PPI |
| kawasan paparan | 107.64(W)×172.224(H) mm |
| saiz garis besar | 114.58(W)×184.09(H) ×3.95(D) mm |
| kecerahan | 390 cd/m² (Typ.) |
| sudut pandangan | 85/85/85/85 (Typ.)(CR≥10) |
| pandangan terbaik pada | Symmetry |
| warna paparan | 16.7M 60% NTSC |
| kekerapan | 60Hz |
| berat panel | TBD |
| voltan masukan | 3.3V (Typ.)(VCI) |
| persekitaran | Operating Temp.: -10 ~ 60 °C ; Storage Temp.: -15 ~ 70 °C |
| model panel | TM080VDSP03 |
| jenis panel | a-Si TFT-LCD , LCM |
| format piksel | RGB Vertical Stripe |
| pembukaan bezel | - |
| permukaan | Hard coating |
| nisbah kontras | 800:1 (Typ.) (TM) |
| mod paparan | SFT, Normally Black, Transmissive |
| masa tindak balas | 25 (Typ.)(Tr+Td) |
| jenis lampu | 7S3P WLED |
| skrin sentuh | Without |
| permohonan | Pad & Tablet |
