| Nombor Bahagian | TM080RBHG30 |
| Jenama | TIANMA |
| Saiz | 8.0 |
| Permohonan | Industrial |
| Resolusi | 800×480 |
| Komposisi | LCM, a-Si TFT-LCD |
| Kecerahan | |
| CR | 500:1 |
| Warna | 262K/16.7M |
| Lampu latar | 3S12P |
| Antara muka | |
| pengilang | TIANMA |
| nama model | TM080RBHG30 |
| saiz skrin | 8.0 inch |
| jenis skrin | LCM, a-Si TFT-LCD |
| nombor piksel | 800(RGB)×480 (WVGA) 116PPI |
| susunan | RGB Vertical Stripe |
| kawasan aktif (mm) | 176.64 × 99.36 (H×V) |
| garis besar (mm) | 192.8 × 116.9 (H×V×D) |
| kawasan bezel (mm) | - |
| rawatan | Antiglare, Hard coating (3H) |
| kecerahan | 375 cd/m² (Typ.) |
| nisbah kontras | 500 : 1 (Typ.) (TM) |
| sudut pandangan | 70/70/60/70 (Typ.)(CR≥10) |
| tindak balas | 25 (Typ.)(Tr+Td) ms |
| pandangan yang baik di | - |
| mod kerja | TN, Normally White, Transmissive |
| kedalaman warna | 262K/16.7M 65% NTSC |
| lampu latar | 3S12P WLED , 20K hours , No Driver |
| jisim | 280g (Typ.) |
| digunakan untuk | Industrial |
| kadar segar semula | 60Hz |
| skrin sentuh | 4-wire Resistive Touch |
| Storage Temp.: -30 ~ 80 °C Operating Temp.: -20 ~ 70 °C |
