| Nombor Bahagian | TM070DVHG01-41 |
| Jenama | TIANMA |
| Saiz | 7.0 |
| Permohonan | Industrial |
| Resolusi | 1024×600 |
| Komposisi | a-Si TFT-LCD , LCM |
| Kecerahan | |
| CR | 500:1 |
| Warna | 16.7M |
| Lampu latar | 3S6P |
| Antara muka | |
| jenama panel | TIANMA |
| saiz panel | 7.0" |
| resolusi | 1024(RGB)×600, WSVGA, 169PPI |
| kawasan paparan | 153.6(W)×90(H) mm |
| saiz garis besar | 171.5(W)×110.3(H) ×5.3(D) mm |
| kecerahan | 270 cd/m² (Typ.) |
| sudut pandangan | 75/75/70/75 (Typ.)(CR≥10) |
| pandangan terbaik pada | 12 o'clock |
| warna paparan | 16.7M 50% NTSC |
| kekerapan | 60Hz |
| berat badan | - |
| model panel | TM070DVHG01-41 |
| jenis panel | a-Si TFT-LCD , LCM |
| format piksel | RGB Vertical Stripe |
| pembukaan bezel | - |
| permukaan | - |
| nisbah kontras | 500:1 (Typ.) (TM) |
| mod paparan | TN, Normally White, Transmissive |
| masa tindak balas | 20 (Typ.)(Tr+Td) |
| jenis lampu | 3S6P WLED , 20K hours , Without Driver |
| skrin sentuh | PCAP |
| permohonan | Industrial |
| AM-800480RWTMQW-TA4H | AMPIRE | 7.0 | 800×480 |
| DLC0700EZG-2 | Other | 7.0 | 800×480 |
| G070VVN01.1 | AUO | 7.0 | 800×480 |
| HJ070NA-13A | Innolux | 7.0 | 1024×600 |
| HSD070IFW1-A00 | HannStar | 7.0 | 1024×600 |
| HV070WSA-100 | BOE | 7.0 | 1024×600 |
| LB070WV7-TL01 | LG Display | 7.0 | 800×480 |
| LQ070Y3LG05 | SHARP | 7.0 | 800×480 |
| PW070XUA | E Ink | 7.0 | 480×234 |
| TM070DDH01 | Tianma | 7.0 | 1024×600 |
