| Nombor Bahagian | TM060JVZG02 |
| Jenama | TIANMA |
| Saiz | 6.0 |
| Permohonan | Medical Imaging |
| Resolusi | 800×1280 |
| Komposisi | LCM , a-Si TFT-LCD |
| Kecerahan | |
| CR | 800:1 |
| Warna | 16.7M |
| Lampu latar | 8S2P |
| Antara muka | MIPI |
| pengilang | TIANMA |
| nama model | TM060JVZG02 |
| saiz skrin | 6.0 inch |
| jenis skrin | LCM , a-Si TFT-LCD |
| nombor piksel | 800(RGB)×1280 (WXGA) 251PPI |
| susunan | RGB Vertical Stripe |
| kawasan aktif (mm) | 80.76 × 129.216 (H×V) |
| garis besar (mm) | 104.16 × 152.62 × 6.5 (H×V×D) |
| kawasan bezel (mm) | - |
| rawatan | Antiglare (Haze 1%) |
| kecerahan | 350 cd/m² (Typ.) |
| nisbah kontras | 800 : 1 (Typ.) (TM) |
| sudut pandangan | 85/85/85/85 (Typ.)(CR≥10) |
| tindak balas | 25 (Typ.)(Tr+Td) ms |
| pandangan yang baik di | Symmetry |
| mod kerja | SFT, Normally Black, Transmissive |
| kedalaman warna | 16.7M 68% NTSC |
| lampu latar | 8S2P WLED , 30K hours , No Driver |
| jisim | TBD |
| digunakan untuk | Medical Imaging |
| kadar segar semula | - |
| skrin sentuh | PCAP |
| jenis isyarat | MIPI (4 data lanes) , 45 pins FPC |
| bekalan voltan | 1.8/5.0/-5.0V (Typ.)(VDDI/AVDD/AVEE) |
| maks. penilaian | Storage Temp.: -30 ~ 80 °C Operating Temp.: -20 ~ 70 °C ; Vibration Level: 2.0G (19.6 m/s²) |
