| Nombor Bahagian | TM050RDH13 |
| Jenama | TIANMA |
| Saiz | 5.0 |
| Permohonan | Automotive Display |
| Resolusi | 800×480 |
| Komposisi | a-Si TFT-LCD , LCM |
| Kecerahan | |
| CR | 500:1 |
| Warna | 16.7M |
| Lampu latar | WLED |
| Antara muka | |
| jenama panel | TIANMA |
| saiz panel | 5.0" |
| resolusi | 800(RGB)×480, WVGA, 188PPI |
| kawasan paparan | 108(W)×64.8(H) mm |
| kecerahan | - |
| sudut pandangan | - |
| pandangan terbaik pada | - |
| warna paparan | 16.7M 50% NTSC |
| kekerapan | 60Hz |
| berat badan | - |
| model panel | TM050RDH13 |
| jenis panel | a-Si TFT-LCD , LCM |
| format piksel | RGB Vertical Stripe |
| pembukaan bezel | - |
| nisbah kontras | 500:1 (Typ.) (TM) |
| mod paparan | TN, Normally White, Transmissive |
| masa tindak balas | 20 (Typ.)(Tr+Td) |
| jenis lampu | WLED |
| skrin sentuh | Without |
| permohonan | Automotive Display |
