| Nombor Bahagian | TM028HDZG59 |
| Jenama | TIANMA |
| Saiz | 2.8 |
| Permohonan | Mobile Phone |
| Resolusi | 240×320 |
| Komposisi | a-Si TFT-LCD , LCM |
| Kecerahan | |
| CR | 400:1 |
| Warna | 65K/262K |
| Lampu latar | WLED |
| Antara muka | 16-bit |
| jenama | TIANMA |
| saiz pepenjuru | 2.8 inch |
| format piksel | 240(RGB)×320 [QVGA] 141PPI |
| kawasan aktif | 43.2(H)×57.6(V) mm |
| kecerahan | 300 cd/m² (Typ.) |
| arah pandang | - |
| sudut pandangan | 70/70/70/58 (Typ.)(CR≥10) |
| warna sokongan | 65K/262K 63% NTSC |
| berat badan | TBD |
| kadar bingkai | - |
| jenis antara muka | 16-bit 8080 parallel , 37 pins FPC |
| bekalan kuasa | 2.7/3.3V (Min./Max.)(VCI/VCC1/VCC2) |
| persekitaran | Operating Temperature: -20 ~ 70 °C ; Storage Temperature: -30 ~ 80 °C |
| model | TM028HDZG59 |
| menaip | a-Si TFT-LCD , LCM |
| konfigurasi | RGB Vertical Stripe |
| garis besar malap. | 50(H)×69.2(V) mm |
| nisbah kontras | 400:1 (Typ.) (TM) |
| masa tindak balas | 25 (Typ.)(Tr+Td) |
| mod operasi | TN, Normally White, Transmissive |
| sumber cahaya | WLED [1S4P] , W/O Driver |
| direka untuk | Mobile Phone |
| panel sentuh | Without |
