| Nombor Bahagian | TM026HDH02 |
| Jenama | TIANMA |
| Saiz | 2.6 |
| Permohonan | Mobile Phone |
| Resolusi | 240×320 |
| Komposisi | LCM , a-Si TFT-LCD |
| Kecerahan | |
| CR | 500:1 |
| Warna | 65K/262K |
| Lampu latar | WLED |
| Antara muka | |
| pengilang | TIANMA |
| nama model | TM026HDH02 |
| saiz skrin | 2.6 inch |
| jenis skrin | LCM , a-Si TFT-LCD |
| nombor piksel | 240(RGB)×320 (QVGA) 156PPI |
| susunan | RGB Vertical Stripe |
| kawasan aktif (mm) | 38.88 × 51.84 (H×V) |
| garis besar (mm) | - |
| kecerahan | 240 cd/m² (Typ.) |
| nisbah kontras | 500 : 1 (Typ.) (TM) |
| sudut pandangan | 70/70/70/60 (Typ.)(CR≥10) |
| tindak balas | 25 (Typ.)(Tr+Td) ms |
| pandangan yang baik di | 6 o'clock |
| mod kerja | TN, Normally White, Transmissive |
| kedalaman warna | 65K/262K 60% NTSC |
| lampu latar | WLED , No Driver |
| jisim | TBD |
| digunakan untuk | Mobile Phone |
| kadar segar semula | - |
| skrin sentuh | Without |
| maks. penilaian | Storage Temp.: -30 ~ 80 °C Operating Temp.: -20 ~ 60 °C |
