AUO T315XW01 V5 lembaran data, spesifikasi, stok, aplikasi www.looklcd-my.com
LookLCD LookLCD


T315XW01 V5

T315XW01 V5
T315XW01 V5
T315XW01 V5
T315XW01 V5 thumb T315XW01 V5 thumb T315XW01 V5 thumb
Jenama
AUO
Saiz
31.5
Permohonan
LCTV
Resolusi
1366×768
Komposisi
LCM
Kecerahan
500
CR
1200:1
Warna
16.7M
Lampu latar
CCFL
Antara muka
LVDS
In Stock
9035
Spesifikasi

Nombor Bahagian T315XW01 V5
JenamaAUO
Saiz31.5
PermohonanLCTV
Resolusi1366×768
KomposisiLCM
Kecerahan500
CR1200:1
Warna16.7M
Lampu latarCCFL
Antara mukaLVDS
jenama panelAUO
model panelT315XW01 V5
jenis panel a-Si TFT-LCD , LCM
saiz panel31.5 inch
resolusi1366(RGB)×768 , WXGA
mod paparanAMVA, Normally Black, Transmissive
kawasan aktif697.685×392.256 mm
garis besar760×450 mm
permukaanAntiglare, Hard coating (3H)
kecerahan500 cd/m² (Typ.)
nisbah kontras1200:1 (Typ.)
warna paparan16.7M (8-bit)
masa tindak balas15/5 (Typ.)(Tr/Td); 8 (Typ.)(G to G)
sudut pandangan88/88/88/88 (Typ.)(CR≥10)(L/R/U/D)
kekerapan60Hz
jenis lampuCCFLEmbedded (Inverter)
antara muka isyaratLVDS (1 ch, 8-bit), 30 pins
voltan masukan5.0V (Typ.)
permohonanLCTV
Model Keluarga
T315XW02 VD AUO 31.5 1366×768
T315XW02 VK AUO 31.5 1366×768
T315XW02 VM AUO 31.5 1366×768
T315XW03 V4 AUO 31.5 1366×768
T315XW03 VD AUO 31.5 1366×768
T315XW04 V0 AUO 31.5 1366×768
T315XW04 V3 AUO 31.5 1366×768
T315XW06 V0 AUO 31.5 1366×768
T315XW06 V3 AUO 31.5 1366×768
T315XW06 V5 AUO 31.5 1366×768
