| Nombor Bahagian | STCG057QVLAM-G02-S |
| Jenama | Kyocera |
| Saiz | 5.7 |
| Permohonan | Industrial |
| Resolusi | 320×240 |
| Komposisi | a-Si TFT-LCD, LCM |
| Kecerahan | |
| CR | 700:1 |
| Warna | 262K |
| Lampu latar | WLED |
| Antara muka | Parallel |
| jenama | Kyocera |
| model | STCG057QVLAM-G02-S |
| saiz pepenjuru | 5.7 inch |
| menaip | a-Si TFT-LCD, LCM |
| format piksel | 320(RGB)×240 [QVGA] 70PPI |
| konfigurasi | RGB Vertical Stripe |
| kawasan aktif | 115.2(H)×86.4(V) mm |
| garis besar malap. | 144(H)×104.8(V) ×13.5(D) mm |
| kawasan bezel | 118.4(H)×89.0(V) mm |
| rawatan | Glare (Haze 0%) |
| kecerahan | 500 cd/m² (Typ.) |
| nisbah kontras | 700:1 (Typ.) (TM) |
| arah pandang | - |
| masa tindak balas | 10/25 (Typ.)(Tr/Td) |
| sudut pandangan | 80/80/80/80 (Typ.)(CR≥5) |
| mod operasi | TN, Normally White, Transmissive |
| warna sokongan | 262K 60% NTSC |
| sumber cahaya | WLED , 40K hours , W/O Driver |
| berat badan | 158g (Typ.) |
| direka untuk | Industrial |
| kadar bingkai | - |
| panel sentuh | Without |
| jenis antara muka | Parallel RGB (1 ch, 6-bit) , 33 pins Connector |
| bekalan kuasa | 3.3V (Typ.) |
| persekitaran | Operating Temperature: -20 ~ 70 °C ; Storage Temperature: -30 ~ 80 °C |
