| Nombor Bahagian | SG8561D01-1 |
| Jenama | CSOT |
| Saiz | 86 |
| Permohonan | TV Sets |
| Resolusi | 3840×2160 |
| Komposisi | a-Si TFT-LCD , CELL |
| Kecerahan | |
| CR | 4000:1 |
| Warna | 1.07B |
| Lampu latar | No |
| Antara muka | V-by-One |
| jenama panel | CSOT |
| saiz panel | 86" |
| resolusi | 3840(RGB)×2160, UHD, 51PPI |
| kawasan paparan | 1895.04(W)×1065.96(H) mm |
| saiz garis besar | 1913.04(W)×1083.96(H) ×1.34(D) mm |
| kecerahan | 0 cd/m² |
| sudut pandangan | 89/89/89/89 (Typ.)(CR≥10) |
| pandangan terbaik pada | Symmetry |
| kedalaman kaca | 0.50+0.50 mm |
| warna paparan | 1.07B 75% DCI-P3 |
| kekerapan | 60Hz |
| ic pemandu | COF Built-in 16 source + 16 gate chips |
| berat panel | 6.50Kgs (Typ.) |
| antara muka isyarat | V-by-One 8 lane , 51 pins Connector |
| voltan masukan | 12.0V (Typ.) |
| persekitaran | Operating Temp.: 0 ~ 50 °C ; Storage Temp.: -20 ~ 60 °C |
| model panel | SG8561D01-1 |
| jenis panel | a-Si TFT-LCD , CELL |
| format piksel | RGB Vertical Stripe |
| pembukaan bezel | - |
| permukaan | Antiglare (Haze 25%), Hard coating (3H) |
| nisbah kontras | 4000:1 (Typ.) (TM) |
| mod paparan | HVA, Normally Black, Transmissive |
| masa tindak balas | 6.5 (Typ.)(G to G) |
| ketransmisian | 5.5% (Typ.)(with Polarizer) |
| jenis lampu | No B/L |
| skrin sentuh | Without |
| permohonan | TV Sets |
