| Nombor Bahagian | S029Q03 |
| Jenama | CDTECH |
| Saiz | 2.9 |
| Permohonan | Stretched Bar LCD |
| Resolusi | 320×120 |
| Komposisi | a-Si TFT-LCD, LCM |
| Kecerahan | |
| CR | 400:1 |
| Warna | 262K |
| Lampu latar | WLED |
| Antara muka | 8/9/16/18-bit |
| jenama | CDTECH |
| model | S029Q03 |
| saiz pepenjuru | 2.9 inch (1/2 cut of 3.5") |
| menaip | a-Si TFT-LCD, LCM |
| format piksel | 320(RGB)×120 115PPI |
| konfigurasi | RGB Vertical Stripe |
| kawasan aktif | 70.08(H)×26.284(V) mm |
| garis besar malap. | 76.9(H)×37.72(V) ×3.46(D) mm |
| kawasan bezel | 72.68(H)×28.88(V) mm |
| rawatan | - |
| kecerahan | 300 cd/m² (Typ.) |
| nisbah kontras | 400:1 (Typ.) (TM) |
| arah pandang | 12 o'clock |
| masa tindak balas | 8/17 (Typ.)(Tr/Td) |
| sudut pandangan | 65/65/55/65 (Typ.)(CR≥10) |
| mod operasi | TN, Normally White, Transmissive |
| warna sokongan | 262K 61% NTSC |
| sumber cahaya | WLED [6S1P] , 30K hours , W/O Driver |
| berat badan | TBD |
| direka untuk | Stretched Bar LCD |
| kadar bingkai | - |
| panel sentuh | Without |
| jenis antara muka | 8/9/16/18-bit 6800/8080 parallel, 6/9/16/18-bit RGB, SPI , 54 pins FPC |
| bekalan kuasa | 3.3/3.3V (Typ.)(VCI/VDDIO) |
| persekitaran | Operating Temperature: -20 ~ 70 °C ; Storage Temperature: -30 ~ 80 °C |
