| Nombor Bahagian | QV101WUB-N80 |
| Jenama | BOE |
| Saiz | 10.1 |
| Permohonan | Industrial |
| Resolusi | 1920×1200 |
| Komposisi | CELL , a-Si TFT-LC |
| Kecerahan | |
| CR | 900:1 |
| Warna | 16.7M |
| Lampu latar | No |
| Antara muka | |
| pengilang | BOE |
| saiz skrin | 10.1 inch |
| nombor piksel | 1920(RGB)×1200 (WUXGA) 224PPI |
| kawasan aktif (mm) | 216.806 × 135.504 (H×V) |
| kawasan bezel (mm) | - |
| kecerahan | 0 (cd/m²) |
| sudut pandangan | 80/80/80/80 (Typ.)(CR≥10) |
| pandangan yang baik di | Symmetry |
| ketebalan kaca | - |
| kedalaman warna | 16.7M 72% NTSC |
| jisim | - |
| kadar segar semula | 60Hz |
| nama model | QV101WUB-N80 |
| jenis skrin | CELL , a-Si TFT-LCD |
| susunan | RGB Vertical Stripe |
| garis besar (mm) | 221.81 × 145.5 (H×V×D) |
| rawatan | Hard coating |
| nisbah kontras | 900 : 1 (Typ.) (TM) |
| mod kerja | ADS, Normally Black, Transmissive |
| tindak balas | 30 (Typ.)(Tr+Td) ms |
| ketransmisian | 3.85% (Typ.)(with Polarizer) |
| lampu latar | No B/L |
| digunakan untuk | Industrial |
| skrin sentuh | Without |
