| Nombor Bahagian | PT320CT01-1 |
| Jenama | HKC |
| Saiz | 32.0 |
| Permohonan | TV Sets |
| Resolusi | 1920×1080 |
| Komposisi | a-Si TFT-LCD, CELL |
| Kecerahan | |
| CR | 3000:1 |
| Warna | 16.7M |
| Lampu latar | No |
| Antara muka | LVDS |
| jenama | HKC |
| model | PT320CT01-1 |
| saiz pepenjuru | 32.0 inch |
| menaip | a-Si TFT-LCD, CELL |
| format piksel | 1920×1080(RGB) [FHD] 69PPI |
| konfigurasi | RGB Horizontal Stripe |
| kawasan aktif | 698.4(H)×392.85(V) mm |
| garis besar malap. | 715(H)×411(V) ×1.39(D) mm |
| kawasan bezel | - |
| rawatan | Antiglare (Haze 3%), Hard coating (3H) |
| kecerahan | 0 cd/m² |
| nisbah kontras | 3000:1 (Typ.) (TM) |
| arah pandang | Symmetry |
| masa tindak balas | 8.5 (Typ.)(G to G) |
| sudut pandangan | 89/89/89/89 (Typ.)(CR≥10) |
| mod operasi | FSA, Normally Black, Transmissive |
| ketebalan plat | 0.50+0.50 mm |
| penghantaran | 5.5% (Typ.)(with Polarizer) |
| warna sokongan | 16.7M 69% NTSC |
| sumber cahaya | No B/L |
| berat badan | 924g (Typ.) |
| direka untuk | TV Sets |
| kadar bingkai | 60Hz |
| panel sentuh | Without |
| perincian d-ic | COF Built-in 2 source chips |
| jenis antara muka | LVDS (2 ch, 8-bit) , 51 pins Connector |
| bekalan kuasa | 12.0V (Typ.) |
| persekitaran | Operating Temperature: 0 ~ 60 °C ; Storage Temperature: -20 ~ 60 °C |
