| Nombor Bahagian | PT156WHM-N10 |
| Jenama | BOE |
| Saiz | 15.6 |
| Permohonan | Industrial |
| Resolusi | 1366×768 |
| Komposisi | a-Si TFT-LCD , LCM |
| Kecerahan | |
| CR | 500:1 |
| Warna | 262K |
| Lampu latar | 10S4P |
| Antara muka | |
| jenama panel | BOE |
| saiz panel | 15.6" |
| resolusi | 1366(RGB)×768, WXGA, 100PPI |
| kawasan paparan | 344.23(W)×193.54(H) mm |
| saiz garis besar | 359.5(W)×223.8(H) ×3.2(D) mm |
| kecerahan | 400 cd/m² (Typ.) |
| sudut pandangan | 45/45/20/40 (Typ.)(CR≥10) |
| pandangan terbaik pada | - |
| warna paparan | 262K 45% NTSC |
| kekerapan | 60Hz |
| berat badan | 370g (Max.) |
| model panel | PT156WHM-N10 (BOE06A5) |
| jenis panel | a-Si TFT-LCD , LCM |
| format piksel | RGB Vertical Stripe |
| pembukaan bezel | - |
| permukaan | Antiglare |
| nisbah kontras | 500:1 (Typ.) (TM) |
| mod paparan | TN, Normally White, Transmissive |
| masa tindak balas | 12 (Typ.)(Tr+Td) |
| jenis lampu | 10S4P WLED , 30K hours , With LED Driver |
| skrin sentuh | Without |
| permohonan | Industrial |
| B156XW02 V0 | AUO | 15.6 | 1366×768 |
| B156XW04 V0 | AUO | 15.6 | 1366×768 |
| LM156WH1-TLE1 | LG Display | 15.6 | 1366×768 |
| LP156WD1-TLD5 | LG Display | 15.6 | 1600×900 |
| LTN156AT01-B02 | Samsung | 15.6 | 1366×768 |
| LTN156AT02-A11 | Samsung | 15.6 | 1366×768 |
| LTN156HT01-201 | Samsung | 15.6 | 1920×1080 |
| M156B1-L01 | Innolux | 15.6 | 1366×768 |
| N156B6-L0A | Innolux | 15.6 | 1366×768 |
| N156BGE-L31 | Innolux | 15.6 | 1366×768 |
