| Nombor Bahagian | P101GWWC R5 |
| Jenama | IVO |
| Saiz | 10.1 |
| Permohonan | Pad & Tablet |
| Resolusi | 800×1280 |
| Komposisi | a-Si TFT-LCD, CELL |
| Kecerahan | |
| CR | 1000:1 |
| Warna | 16.7M |
| Lampu latar | No |
| Antara muka | MIPI |
| jenama | IVO |
| model | P101GWWC R5 |
| saiz pepenjuru | 10.1 inch |
| menaip | a-Si TFT-LCD, CELL |
| format piksel | 800(RGB)×1280 [WXGA] 150PPI |
| konfigurasi | RGB Vertical Stripe |
| kawasan aktif | 135.36(H)×216.576(V) mm |
| garis besar malap. | 139.36(H)×225.8(V) ×1.06(D) mm |
| kawasan bezel | - |
| rawatan | Antiglare |
| kecerahan | 0 cd/m² |
| nisbah kontras | 1000:1 (Typ.) (TM) |
| arah pandang | Symmetry |
| masa tindak balas | 30 (Typ.)(Tr+Td) |
| sudut pandangan | 85/85/85/85 (Typ.)(CR≥10) |
| mod operasi | IPS, Normally Black, Transmissive |
| ketebalan plat | 0.40+0.40 mm |
| penghantaran | 6.2% (Typ.) |
| warna sokongan | 16.7M 60% NTSC |
| sumber cahaya | No B/L |
| berat badan | 85.0g (Max.) |
| direka untuk | Pad & Tablet |
| kadar bingkai | 60Hz |
| panel sentuh | Without |
| perincian d-ic | COG Built-in 1 source chips |
| jenis antara muka | MIPI (4 data lanes) , 39 pins Connector |
| bekalan kuasa | 3.3V (Typ.) |
| persekitaran | Operating Temperature: 0 ~ 50 °C ; Storage Temperature: -20 ~ 60 °C |
| AM-1280800N2TZQW-00H | AMPIRE | 10.1 | 1280×800 |
| B101EAN01.2 | AUO | 10.1 | 1280×800 |
| B101EW05 V1 | AUO | 10.1 | 1280×800 |
| CLAA101WJ03 XG | CPT | 10.1 | 1366×768 |
| G101AGE-L01 | Innolux | 10.1 | 800×600 |
| HSD101PWW1-A00-C40 | HannStar | 10.1 | 1280×800 |
| HSD101PWW1-F01 | HannStar | 10.1 | 1280×800 |
| M101GWN9 R0 | IVO | 10.1 | 1024×600 |
| M101MWW4 R0 | IVO | 10.1 | 1024×600 |
| Q101IRE-LA1 | Innolux | 10.1 | 1280×800 |
