| Nombor Bahagian | NV140FHM-N66 |
| Jenama | BOE |
| Saiz | 14.0 |
| Permohonan | Laptop |
| Resolusi | 1920×1080 |
| Komposisi | LCM , a-Si TFT-LCD |
| Kecerahan | |
| CR | 800:1 |
| Warna | 16.2M |
| Lampu latar | 10S5P |
| Antara muka | eDP |
| pengilang | BOE |
| nama model | NV140FHM-N66 (BOE08B5) |
| saiz skrin | 14.0 inch |
| jenis skrin | LCM , a-Si TFT-LCD |
| nombor piksel | 1920(RGB)×1080 (FHD) 157PPI |
| susunan | RGB Vertical Stripe |
| kawasan aktif (mm) | 309.312 × 173.988 (H×V) |
| garis besar (mm) | 314.31 × 191.09 × 2.6 (H×V×D) |
| kawasan bezel (mm) | - |
| rawatan | Antiglare, Hard coating (3H) |
| kecerahan | 300 cd/m² (Typ.) |
| nisbah kontras | 800 : 1 (Typ.) (TM) |
| sudut pandangan | 85/85/85/85 (Typ.)(CR≥10) |
| tindak balas | 20 (Typ.)(Tr+Td) ms |
| pandangan yang baik di | Symmetry |
| mod kerja | ADS, Normally Black, Transmissive |
| kedalaman warna | 16.2M 100% sRGB |
| lampu latar | 10S5P WLED , 15K hours , With LED Driver |
| bentuk garis besar | Slim (PCBA Flat, T≤3.2mm) |
| digunakan untuk | Laptop |
| kadar segar semula | 60Hz |
| skrin sentuh | Without |
| jenis isyarat | eDP (2 Lanes) , eDP1.2 , HBR1 (2.7G/lane) , 30 pins Connector |
| bekalan voltan | 3.3V (Typ.) |
| maks. penilaian | Storage Temp.: -20 ~ 60 °C Operating Temp.: 0 ~ 50 °C |
