| Nombor Bahagian | NT156WHM-N40 |
| Jenama | BOE |
| Saiz | 15.6 |
| Permohonan | Laptop |
| Resolusi | 1366×768 |
| Komposisi | LCM , a-Si TFT-LCD |
| Kecerahan | |
| CR | 400:1 |
| Warna | 262K |
| Lampu latar | WLED |
| Antara muka | eDP |
| pengilang | BOE |
| nama model | NT156WHM-N40 |
| saiz skrin | 15.6 inch |
| jenis skrin | LCM , a-Si TFT-LCD |
| nombor piksel | 1366(RGB)×768 (WXGA) 100PPI |
| susunan | RGB Vertical Stripe |
| kawasan aktif (mm) | 344.232 × 193.536 (H×V) |
| garis besar (mm) | - |
| kecerahan | - |
| nisbah kontras | 400 : 1 (Typ.) (TM) |
| sudut pandangan | 45/45/20/40 (Typ.)(CR≥10) |
| tindak balas | 12 (Typ.)(Tr+Td) ms |
| pandangan yang baik di | 6 o'clock |
| mod kerja | TN, Normally White, Transmissive |
| kedalaman warna | 262K |
| lampu latar | WLED , 15K hours , With LED Driver |
| bentuk garis besar | Slim (PCBA Flat, T≤3.2mm) |
| digunakan untuk | Laptop |
| kadar segar semula | 60Hz |
| skrin sentuh | Without |
| jenis isyarat | eDP (1 Lane) , 30 pins Connector |
| bekalan voltan | 3.3V (Typ.) |
| maks. penilaian | Storage Temp.: -20 ~ 60 °C Operating Temp.: 0 ~ 50 °C |
